JP-33 SERVICE MANUAL
212 F63-14005B Plate Washer φ4
8
SUS316
213 F63-12002 Shaft B for Rack Drive
1
SUS316 φ8 x 471.2
214 F63-13001 Roller-Rubber
5
SUS316 w/Rubber
215 F63-13002 Roller-PVC
3
SUS316 w/PVC
216 F63-12005A Stud for Idle Gear and rack mounting
2
SUS316 φ8 x 33.5
217 F63-11026 Bushing of Roller
19
PBT Black
218 F63-13004A Spring A (in Large type)
4
SUS316 0.5t 20 x 65
219 F63-13004B Spring C (out Large type)
4
SUS316 0.5t 20 x 65
220 F63-14004A Screw PH Tapping 3 x 10
8
SUS316
221 F63-11025 Gear worm Wheel
1
PBT Black
222 F63-11022 Gear A of 0.8" D-cut
8
PBT Black
223 F63-11023 Gear B of 1.5" Idle
2
PBT Black
224 F63-11024 Gear-C of 1.5" D-cut
1
PBT Black
225 F63-14001 Snap Ring type "C"
2
SUS316 φ7
226 F63-14002 Snap Ring type "E"
12
SUS316 φ7
F63-00006
Wash rack assembly
227 F63-11029A Rack side plate Wash L
1
ABS w/glass 15%, Black color
228 F63-11029B Rack side plate Wash R
1
ABS w/glass 15%, Black color
229 F63-11020 Film Guide A Large
3
ABS Natural, Clean color
230 F63-11021 Film Guide B Small
2
ABS Natural, Clean color
231 F63-11031
Film Guide C for Fix, Wash Crossover
4
F62-5902, common
232 F63-12003 Shaft C for Film Guide, Spacer
8
SUS316 φ6 x 376
233 F63-12003B Shaft D for Film Guide C
2
SUS316 φ6 x 375
234 F63-14003 Screw PH M3 x 12
24
SUS316
235 F63-14005 Spring washer M3
12
SUS316
236 F63-14005B Plate Washer φ4
8
SUS316
237 F63-12002 Shaft B for Rack Drive
1
SUS316 φ8 x 471.2
238 F63-13001 Roller-rubber
8
SUS316 w/Rubber
239 F63-13002 Roller-PVC
4
SUS316 w/PVC
240 F63-13003 Roller-phenol
2
SUS316 w/Phenol
241 F63-12005 Stud for Idle Gear
6
SUS316 φ8 x 26
242 F63-12005A Stud for Idle Gear and rack mounting
2
SUS316 φ8 x 33.5
242 F63-11026 Bushing of Roller
31
PBT Black
243 F63-13004A Spring A (in Large type)
2
SUS316 0.5t 20 x 65
244 F63-13004B Spring C (out Large type)
2
SUS316 0.5t 20 x 65
245 F63-13005A Spring B (in Small type)
10
SUS316 0.5t 20 x 45
246 F63-13005B Spring D (out Small type)
10
SUS316 0.5t 20 x 45
247 F63-11025 Gear worm Wheel
1
PBT Black
248 F63-11022 Gear A of 0.8" D-cut
14
PBT Black
249 F63-11023 Gear B of 1.5" Idle
7
PBT Black
250 F63-11024 Gear-C of 1.5" D-cut
1
PBT Black
251 F63-14001 Snap Ring type "C"
8
SUS316 φ7
252 F63-14002 Snap Ring type "E"
18
SUS316 φ7
253 F63-13019 Air pipe for Dryer
4
ABS Molding, Grey Color
254 F63-11030 Pusher dry roller
2
PBT Black
255 F63-12013 Inner cover A for Dryer
1
Plastic SUS316 1.6t 376 x 80
256 F63-12014 Inner cover B for Dryer
1
Plastic 1.6t 376 x 115
257 F63-13021 Inner Case of Dryer
1
Plastic 0.6t 376 x 210
258 F63-14009A Hoses Diameter-In φ8.0
1
Silicon Red, Blue, Clean
259 F63-14009B Hoses Diameter-In φ12.0
1
Silicon Red, Blue
260 F63-14009C Hoses Diameter-In φ16.0
1
Silicon Red, Blue, Clean
Spare Parts Pack in Beaker
261 F63-11026 Bushing of Roller
5
PBT Black
262 F63-11022 Gear A of 0.8" D-cut
2
PBT Black
- -
58
