JP-33 SERVICE MANUAL
78 F63-22015 Wire Yellow for Dry Heater Wiring
1
Teflon φ1.25, UL
79 F63-22011 Wire Green/Yellow for Ground
1
Teflon φ1.25, UL
Blower Fan Assembly
80 F63-21002 Blower Fan
1
ebm G2E 108-AA 01-01
81 F63-14004E Screw PH Tapping 4 x 16
2
SUS316
82 F63-21003 Capacitor for Blower Fan
1
450VA 1.5uF
83 F63-14004E Screw PH Tapping 4 x 16
1
SUS316
84 F63-13007 Bracket for Blower Fan
1
SUS316 1.6t 72 X 90
85 F63-14003D Screw PH M4 x 8
2
SUS316
86 F63-14004D Screw PH Tapping 4 x 12
2
SUS316
87 F63-22018 Wire 1.25 Brown for Blow-Fan Wiring
1
Teflon 1.25pie, UL
Main Motor Assembly
88 F63-21001 Main Motor w/ Capacitor
1
15W 70 X 70 with Capacitor 1.2uF
89 F63-14004E Screw PH Tapping 4 x 16
1
SUS316
90 F63-21001A Reducer for 60Hz Only
1
STD 25:1, VS.18:1, 50Hz 18:1
91 F63-13006 Bracket of main motor
1
SUS316 2.0t 100 x 150
92 F63-14004 Screw PH Tapping 4 x 20
4
SUS316
93 F63-14007A Sprocket A (inside hole Φ10)
1
Type No.25 Tooth 19, Tapping M4
94 F63-14006 Wrench Bolt Hex M4 x 8
1
SUS316
95 F63-14008 Chain of Min motor
1
Type No.25/ Length 271.5mm/ 42P
tp F63-13006A Spacer of main motor bracket
4
SUS316 φ8 x 5.5t
96 F63-22016 Wire 1.25 Orange for Main-Motor
1
Teflon 1.25pie, UL
Switch of Main power Assembly
97 F63-21013 Switch of Main power
1
16A250V ACT125
98 F63-21014 Fuse Holder
2
250V 20A FEU 0031-1673
99 F63-21015 Fuse
2
250V 8A, DIA 6.3 x 32mm
100 F63-22017 Wire 1.25 Black for AC in-put Wiring
1
Teflon 1.25pie, UL
101 F63-22006 Terminal of Clip Type Large
3
Terminal w/ insulation Tube
Bracket of Foot Bolt Assembly
102 F63-11015 Bracket of Foot Bolt
4
HIPS 401AF, Grey color w/Tap
103 F63-32005 Foot Bolt
4
M12 X 40L w/Rubber foot
F63-00009
Heater of DEV Assembly
104 F63-21006 Heater of DEV, with Thermostat
1
220V 900W with Thermostat 65N
105 F63-21022 Thermostat Extra (DEV Heater Outer)
1
PW-65N
106 F63-12008 Pipe for FIX Heating
1
SUS316 Pipe φ8 x 200
107 F63-12057 Pipe for DEV heating (L)
1
SUS316 Pipe φ8 x 50 with Tap M8
108 F63-12058 Pipe for DEV heating (S)
1
SUS316 Pipe φ8 x 40 with Tap M8
109 F63-12009
Stainless core (for Temp. Exchange)
1
SUS 304 φ20 x100 with φ8 hole x2
110 F63-13009 Bracket for DEV Heater
2
SUS316 1.0t 40 x 140
111 F63-14004E Screw PH Tapping 4 x 16
2
SUS316
112 F63-43006 Silicon Compound for Heat-sink
1
DC HCC 435
113 F63-14011A Hose Band φ12.8, Ear Clamp
4
SUS 316
114 F63-22014 Wire 1.25 Red for DEV-Heater Wiring
1
Teflon 1.25pie, UL
F63-00010
DEV Sensor Assembly
115 F63-21007 Sensor of DEV Temp.
1
PT-100
116 F63-12010 Pipe of DEV Sensor
1
SUS316 Pipe φ8 x 70
117 F63-43001 Sponge for DEV Sensor
1
10t 100 x 100
118 F63-43005 Teflon Tape for DEV Sensor
1
Sealing Tape
119 F63-14011A Hose Band φ12.8, Ear Clamp
2
SUS 316
Plumbing
120 F63-12015 Nipple "T" for RPL coupling(DEV, FIX)
2
SUS316 Pipe φ8 x 80,φ12 X 40
- -
55
To Next Page
