JP-33 SERVICE MANUAL
121 F63-14011A Hose Band φ12.8, Ear Clamp
4
SUS316
122 F63-14011F Hose Band φ19.5, Ear Clamp
2
SUS 316
Power Cord Assembly
123 F63-21017 Power cord w/Bushing
1
AC250V 16A H05VV-F
124 F63-13023 Bracket of AC Cord
1
SUS316 1.5t 30 x 80
125 F63-14004D Screw PH Tapping 4 x 12
2
SUS316
126 F63-13020 Bracket for Main Body
1
SUS316 2.0t 30 x 380
F63-00011
Dry Heater Assembly
127 F63-21012 Heater of Dry
1
1.0Kw w/thermostat, thermo-fuse
128 F63-13011 Case for Dry Heater
1
SUS316 1.6t 85 x 340, 120 x 110
129 F63-12026 Ground Pin for Dry ESD
1
SUS 316 φ1.0 x 100
130 F63-13011B Net for Dry Heater case
1
SUS316 Net Mash
131 F63-13012 Bracket for Dry Heater
1
SUS316 1.6t 90 x 90
132 F63-14004D Screw PH Tapping 4 x 12
6
SUS316
133 F63-22008 Wire-Connection for Dry Heater
2
UL, Yellow Cap Insulator
134 F63-12019 Insulator for Dry Heater coil
1
Mica 1.0t 80 x 160 Dry Heater
F63-00012
Sensor of Water level Assembly
135 F63-21011 Sensor of Water level
1
Material PVC, DLF-103
136 F63-13010 Bracket for Level Sensor
1
SUS316 20 x 80 with painting
137 F63-13004D Screw PH Tapping 4 x 12
1
SUS316
Control PCB Assembly
138 F63-11003 Case of Control PCB
1
HIPS 401AF, Grey color
139 F63-12004 Cover of Control PCB
1
ABS, Natural
140 F63-12017 Stud of Control Cover
4
Acetyl φ5 x 10
141 F63-23002 PCB Assembly for Control
1
PCB Assembly Parts List
142 F63-14004C Screw PH Tapping 4 x 10
3
SUS316
143 F63-14004A Screw PH Tapping 3 x 10
2
SUS316
144 F63-14017 Mount of Cable
1
PVC w/양면 Tape
145 F63-43019 Rubber Sheet of Control Cover
1
Silicon Rubber
146 F63-12059 Bracket of Rubber Holder
2
ABS 2t x 5 x 50
147 F63-12060 Plate of Control Case Inner
1
PE Sheet 1.5t x 50 x 50
Rack Lock Assembly
148 F63-12031 Locker of Rack
3
Plastic
149 F63-12032 Space of Rack Locker
3
SUS316 φ6.1 x 7.1t
150 F63-14005B Plate Washer φ4
3
SUS316
151 F63-14004E Screw PH Tapping 4 x 16
3
SUS316
152 F63-12021 Drain Filter Assembly
3
SUS Bracket 2pcs w/ SUS Net
153 F63-12011 Cover Plate of Tank Inlet Hole
3
ABS 3.0t 56 x 100
154 F63-14004C Screw PH Tapping 4 x 10
6
SUS316 Rack Locker Hole
F63-00003
Door Assembly
155 F63-11016 Door-Top
1
HIPS 401AF, Grey color
156 F63-11017 Door-Bottom
1
HIPS 401AF, Grey color
157 F63-11018 Door Hinge
1
HIPS 401AF, Grey color
158 F63-11019 Door Decoration
1
HIPS 401AF with Blue painting
159 F63-12006 Hinge pin A (large) of Door
1
SUS316 φ6 x 27.8
160 F63-12006B Hinge Pipe (large) of Door
1
SUS316 φ6 x 27.8 Pipe
161 F63-12007 Hinge pin B (small) of Door
2
SUS316 φ4 x 27.8
162 F63-14004B Screw PH Tapping 3 x 12
7
SUS316
163 F63-43004C Rubber Sponge of Door shield
1
5t 10 x 380
164 F63-12028 Bracket of Door Shield
1
SUS316 361 x 30 x 13 x 1.0t
- -
56
