27
XF631 MANUAL • CHAPTER 7: Functions (Function Mode)
CHAPTER 7: Functions (Function Mode) continued
The amount of servo travel is adjustable for each
direction for each of the 6 channels individually. The
adjustment range is from 0% to 150%. Travel
adjustment is factory set at 100% for all channels.
The travel adjustment value displayed on the screen
depends on the position of the stick or switch (e.g.,
flap switch, gear switch). This function is useful either
to maximize control surface travel or to reduce travel
to eliminate servo binding without the need for
mechanical adjustment.
1. Turn on the transmitter.
2. Press the Scroll and Increase buttons up
simultaneously to enter the Function Mode.
3. Press the Scroll button until “TRV ADJ.” appears on
the screen.
4. Press the Channel button until the desired
channel appears on the screen.
5. Move the selected channel stick or switch in the
direction that you want to adjust the travel.
Press the Increase or Decrease button to achieve
the desired travel. Move the stick in the
opposite direction to adjust the travel in the
opposite direction.
6. The same may be done for all channels.
7. Press the Scroll button to access the Servo
Reverse function.
8. To exit, press the Scroll and Increase buttons
up simultaneously.
Accessing the Travel Adjustment Function
TRAVEL ADJUSTMENT
•
Function Mode
7.4
To Next Page
