XF631 MANUAL • INTRODUCTION 2: Features
INTRODUCTION 2: Features continued
537 Servo
• An ultra-tight deadband amplifier ensures
accurate neutral centering
• Low current drain
• Ball bearing supported ouput shaft with new
wide spacing for improved precision
• An indirect drive feedback potentiometer gives
additional protection from vibration
SERVO FEATURES2.3
SERVO LAYOUT
2.4
Servo Mounting Flange
Rubber Grommets
Rubber Grommets
Servo Case
Servo Lead w/Connector
Servo Output Shaft
Servo Mounting Flange
Servo Arm/Horn
Servo Arm Retaining Screw
Servo Eyelet
Top View
