20.1.5 Fuse inspection
Because there is a specific cause for any fuse meltdown, it is necessary to check the related circuits
even if there is no abnormality after changing a fuse. However, please give consideration that the fuse
meltdown characteristics vary significantly. The following table shows a list of the fuses used in this
unit.
List of Fuses Used
Fuse Name Name of
Model Used
Placement
Location
Count Part Spec. Change Kit Model
Name
Blade fuse
(Auto fuse)
NBD-913 Power
supply unit
2 32VDC 15A part 1015(5ZFCK00008)
Blade (mini) fuse
(Auto fuse)
NQE-1143 JB 1 32VDC 15A part 1215(5ZFCK00017)
Blade (mini) fuse
(Auto fuse)
2 32VDC 3A part 1203(5ZFCK00016)
Glass fuse 4 250V 0.5A part MF51NR 250V
0.5(5ZFGD00019)
