Appendix B
Menu List and Materials
B-160
B.10.5
User Chart File
(1) Header record
Line Content
Description
Import
1
// (space)
Fixed string
USER CHART
SHEET exported by JRC ECDIS.
Fixed string
2
// (space)
Fixed string
<<NOTE>>This string
s // indicate comment
column/cells.
Y
ou can edit freely
.
V
ariable-length string
3
// (space)
Fixed string
User Chart Name
Name of the
source file
,
Fixed c
haracter
,
Fixed c
haracter
User Chart Comment
Comment in the source
file
339
341
