Setting Item Description of Setting Setting Value
Radio button on the left
side of each CCRP
Select the position to be used as the ship's CCRP
by clicking the applicable button.
CCRP1
CCRP2
CCRP3
CCRP4
Anchor1 An anchor position can be set as an offset from the
stern center.
It can not be set outside the boat.
X: The horizontal axis position on the shipboard of
Anchor 1 (center is 0)
Y: Front-rear axis position on the shipboard of
Anchor 1 (stern is 0)
If Length=a and Beam=b:
X -b/2 to b/2
Y 0.0 to a
Anchor2 An anchor position can be set as an offset from the
stern center.
It can not be set outside the boat.
X: The horizontal axis position on the shipboard of
Anchor 2(center is 0)
Y: Front-rear axis position on the shipboard of
Anchor 2 (stern is 0)
If Length=a and Beam=b:
X -b/2 to b/2
Y 0.0 to a
Speed Position Bow
Enter the distance to the bow starboard/port speed
display point.
0.0 to Ship's length m
Speed Position Stern
Enter the distance to the stern starboard/port
speed display point.
0.0 to Ship's length m
Synchronizing setting
The [CCRP] dialog enables common setting items and individual setting items for RADAR, ECDIS, and
Conning (called a task station individually). Once common items are set in any of the task stations,
RADAR, ECDIS, and Conning, the settings are reflected (synchronized) in other task stations.
By setting common items in the state where all the task stations are active, the common setting items
are synchronized in all the task stations.
17.3.3 Setting a Serial Port
Verify the setting of the serial port of this equipment and perform initial setting by using the [Serial Port]
dialog.
Synchronizing setting
The [Serial Port] dialog enables common setting items and individual setting items for RADAR, ECDIS,
and Conning (called a task station individually). Once common items are set in any of the task stations,
RADAR, ECDIS, and Conning, the settings are reflected (synchronized) in other task stations.
By setting common items in the state where all the task stations are active, the common setting items
are synchronized in all the task stations.
