22-13 Section 22 Specifications
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
22
23
25
26
27
付録
22.12 19inch Display Unit Mount Kit
GENERAL SPECIFICATION CWA-245: 19inch DISPLAY UNIT MOUNT KIT
Structure
Dimension Width 580 × Depth 718 × Height 1100 (mm)
Mass Approx. 55kg
Environment
Operational Temperature -15ï‚°C to +55ï‚°C
Operational Humidity 40ï‚°C RH 93%
Vibration
Sweep 2 Hz to 13.2 Hz at ± 1 mm, 13.2 Hz to 100 Hz at 7m/s2
and for 2h on each resonance, otherwise 2h at 30Hz in all three
axes
EMC IEC60945-Ed4.0
Ingress Protection Rating Front: IP22
