Section 17 Adjusting and Setting up Equipment (for Services) 17-10
17.3.2.2 Setting CCRP
Set the following items in the [CCRP] dialog.
Setting Item Description of Setting Setting Value
Length (of ship) Enter the ship's length in the box. 1.0 to 1022.0m
Beam (ship's width) Enter the ship's width in the box. 1.0 to 126.0m
GPSx
(When two or more
GPS units are present,
"x" indicates the unit
number.)
Enter the equipment positions of GPSx in the
boxes.
X: Horizontal axis position on the ship of the
applicable GPS (Center: 0)
Y: Front-back axis position on the ship of the
applicable GPS (Stern: 0)
Note
• This item may not be displayed depending on the
equipment setting.
• When the input range is changed by modifying
[Length] and [Beam], if a value exceeding the
input range after modifying has already been
entered, the value will be corrected to the
maximum or minimum value.
Changes depending on the
value of [Length] and [Beam].
If Length=a and Beam=b:
X -b/2 to b/2
Y 0.0 to a
For example,
• if Length=1.0 and Beam=1.0:
X -0.5 to 0.5
Y 0.0 to 1.0
• if Length=700.0 and
Beam=70.0:
X -35.0 to 35.0
Y 0.0 to 700.0
Radar Antennas1 to 8
(equipment positions of
radar antennas1 to 8)
Enter the equipment positions of Radar Antennas1
to 8 in the boxes.
X: Horizontal axis position of radar antennas 1 to 8
on the ship (Center: 0)
Y: Front-back axis position of radar antennas 1 to 8
on the ship (Stern: 0)
Note
• If "No Equipment" is specified in the [DipSW]
settings of the interswitch unit, this is not
displayed.
• When the input range is changed by modifying
[Length] and [Beam], if a value exceeding the
input range after modifying has already been
entered, the value will be corrected to the
maximum or minimum value.
CCRP1/2/3/4 Enter the positions of CCRP1 to CCRP4 of the
ship in the boxes.
X: Horizontal axis position of CCRP1/2/3/4 on the
ship (Center: 0)
Y: Front-back axis position of CCRP1/2/3/4 on the
ship (Stern: 0)
Note
When the input range is changed by modifying
[Length] and [Beam], if a value exceeding the input
range after modifying has already been entered,
the value will be corrected to the maximum or
minimum value.
To Next Page
