JRC JAN-9201 Instruction Manual

Section 22 Specifications 22-6
22.4 Central Control Unit
GENERAL SPECIFICATION NDC-1590: Central Control Unit
CPU Intel Core i5 2515E 2.5GHz (NDC-1590)
/ CPU Intel Core i3 6100E 2.7GHz (NDC-1590A)
Main Memory 2GB (DDR3, NDC-1590) / 4GB (DDR4, NDC-1590A)
JRC ASIC Yes
Mechanical
Dimension Width 400 x Depth 240 x Height 125 (mm)
Mass 5.6kg
FAN 1
Environment
Operational Temperature -15°C to +55°C
Operational Humidity 40°C RH 93%
Vibration Sweep 2 Hz to 13.2 Hz at ± 1 mm, 13.2Hz to 100Hz at 7m/s
2
and
for 2h on each resonance, otherwise 2h at 30Hz in all three axes
EMC IEC60945-Ed4.0
Ingress Protection Rating IP20
Interfaces
DVI-D 1
VGA 1 (Slave output with same resolution as DVI-D)
IEC61162-1 2 input (GPS and LOG)
IEC61162-2 2 input (AIS and THD)
IEC61162-450 2 (IEEE802.3u/IEEE802.3ab compliance
(100BASE-TX/1000BASE-T))
Dry Contact Output 2 (Power Fail and Watch Timer Reset )
Normally Close Power Fail (32V 0.8A MAX)
Normally Open Watch Timer Reset (32V 0.8A MAX)
Operation Unit 1 (5m max)
Extended Operation Unit 1 (up to 30m)
USB I/F 3 (1 for MNU, Others are general purpose)
RADAR I/F 1 input for scanner unit, 1 output for other equipment
Power Connecting with NBD-913
