JRC JAN-9201 Instruction Manual

22-11 Section 22 Specifications
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
22
23
25
26
27
付録
22.9 26inch Display
GENERAL SPECIFICATION NWZ-208: Display
Screen Size
26inch
Aspect Ratio 16:10
Full Resolution 1920  1200RB
Supported format
1920  1200RB, 1680  1050, 1680  1050RB, 1600 
1200, 1600  1200RB, 1280  1024, 1024  768, 800  600,
640  480
Dot Pitch 0.2865 mm
Viewing Area 550.08 mm  343.8 mm
Display Colors 16.77 million colors
Contrast Ratio 1500:1
Viewing Angles (H / V) 176°/176°
Back Light LED
Brightness 400cd/m
2
Type
Digital Scanning Frequency (H / V)
Horizon 30 kHz to 75 kHz
Vertical 56 Hz to 75 Hz
DVI-D input 1
VGA input 1
VGA output 1
USB I/F 1
Power
21.6 to 31.2VDC
85 to 265VAC 50/60Hz
Overvoltage Protection N/A
DC Reverse Connection Protection Self-Return Type
Cables Up to 5 m
Glass Bonding Optional
Mechanical
Dimension Width 624 x Depth 85 x Height 456 (mm)
Mass 16kg
Fan 2
Glass Tempered Glass + AR Coating
Environment
Operational Temperature -15C to +55C
Operational Humidity 40C RH 93%
Vibration
Sweep 2 Hz to 13.2Hz at ± 1 mm, 13.2 Hz to 100 Hz at
7m/s
2
and for 2h on each resonance, otherwise 2h at 30Hz
in all three axes
EMC IEC60945-Ed4.0
Ingress Protection Rating Front: IP65 Back: IP22
