JRC JAN-9201 Instruction Manual

22-17 Section 22 Specifications
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
22
23
25
26
27
付録
FUNCTIONAL SPECIFICATION CQD-2286: Radar Interface Circuit
Interface
Scanner Input 1
Slave Video output 1
Radar video
0 to 2.6 VDC, output with 50 ohm termination, log scale:
50dB/V
Trigger
Positive, 4V, 1us, output with 50 ohm termination
BP (:Bearing Pulse)
2048 pulse/round, open-collector output with 5V-1k ohm
pull-up
BZ (:Bearing Zero)
1 pulse/round, open-collector output with 5V-1k ohm pull-up
ISW YES
