JRC JHS-182 - Lost Terget Alarm Setting; User Alarm Histroy

5-40
5.3.3.2 LOST TERGET ALARM SETTING
To set the Lost Target alarm, select 2. LOST TERGET in the USER ALARM SETTING menu. If the
information of a other ship in the Lost Terget range for more than six minutes, a warning
message-“LOST” is displayed and the buzzer beeps. The display/alarm can be cleared by CLR.
1.
(1). From USER ALARM SETTING MENU, use the Jog Dial and select 2.LOST TARGET
(2). With the Jog Dial, input the radius.(see 5.3.3 for numeric input)
① Set the distance which is sufficiently possible to communicate
② When the Jog Dial is pressed, the selection is confirmed.
③ When CLR key is pressed, the selection is canceled.
(3). The cursor jumps to BUZZER: , then select and confirm ON/OFF by the Jog Dial.
(4). The cursor jumps to the next item.
5.3.3.3 USER ALARM HISTORY

When USER ALARM HISTORY is selected, USER ALARM HISTORY Screen appears.
The day and time of the alarms above are recorded.
The newest record comes to the top.
The newest ten records are displayed and older records are discarded.
When CLR key is pressed, USER ALARM SETTING Screen appears.













USERALMHISTORYUTC11:44
BRG:RNG NAME/MMSI
270 ° :0.18NM
35
° :0.29NM
*22
° :0.92NM
OCEAN-LINE
QUEEN
ABCDEFG-MARU
1.2004/01/0112:34GUARD
2.2003/12/3123:40GUARD
3.2003/12/3123:34GUARD
4.2003/12/3110:10LOST
5.2003/12/2112:00GUARD
6.2003/11/0912:59GUARD
7.2003/11/0912:58GUARD
8.2003/11/0912:57LOST
9.2003/11/0712:01LOST
10.2003/11/0119:48GUARD



USER ALARM HISTORY Screen
