2-5
3. Connect the included cable to the sensor unit. Tighten the nut firmly in order to waterproof
the connector (a click sounds when plugged in firmly).
After connecting, apply RTV rubber on the connector for additional waterproofing.
3. With using the included bundling band (short), clamp the cable as shown below. Position
should be between GPS1 and GPS2.
Waterproofing
Bundling band (short)
(Clamp the small clamp filter.)
BOW
GPS3
GPS1 GPS2
