Magnetron Replacement Procedure for Scanner Unit NKE-2254
(JMA-5322-7/9/6HS)
(1)
Before beginning
work, tu
rn of
f the safety switch
located on the
bottom of the stern side
of the
scanner unit.
Bow direction
T
urn off the safety
switch.
Bow
direction
(2)
Loosen the hexagonal
bolts an
d remove the c
over on the
right (starboa
rd) side.
Loosen the four
hexagonal bolt
s.
Magnetron cove
r
(3)
Loosen the screws (four M
4 screws) t
o remove the
magnetron co
ver
.
Loosen the
four screws.
8-17
