3.8 Use Route Function
y
y y
3.7.2 Receive Route Data Setting (Select Route)
The system can receive data from other system via the JRC-LAN. The JRC-LAN is designed for
interoperation of JRC systems. The JRC-LAN network can synchronize data of systems connected
to the network.
The Plotter Control Unit (option) is necessary.
The setting of the Route Type is necessary for receiving route data. Refer to "Section 7.2.11
Transmit/Receive Data Setting"
3
*When the system display Route which are created in the ECDIS or Chart RADAR, following items
are not displayed.
• XTL
• Arrival Radius
• ROT
• Turn Radius
• Time Zone
• Sail
Procedures 1 Press the [RADAR MENU] key.
2 Open the Select Route menu by performing the following menu
operation.
7. Plot Menu
→ 3. WPT/Route Setting
→ 4. Select Route
3. Select the data to be displayed.
The NMEA Waypoint Display is turned on or off.
Off : Route is not displayed.
Internal : Internal route data is displayed.
NMEA : Destination marks are displayed by using WPT data sent from
outside navigation equipment.
ECDIS : Route created in the ECDIS and GPS are displayed.
When On is selected, the â—‹WP mark appears of the display.
The destination mark is displayed only when Waypoint data is received from outside
by the NMEA sentence (RMB,BWC,BWR).
3-80
