7.1.6 Navigator Setting (Device)
Determine whether to connect navigators to the radar equipment.
Only the navigators set to ON here can be used.
Procedures 1. Open the Serviceman Menu.
2. Open the Device Installation menu by performing the following menu
operation.
2. Installation Menu
→ 9. Next
→ 3. Device Installation
3. Select On for navigators connected to the radar equipment, and
Off for navigators not connected.
GYRO : Gyro (via GYRO I/F)
Compass : Compass (Compliant with IEC61162)
GPS Compass : GPS compass produced by JRC
Log : Log (via GYRO I/F)
2AXW : 2-axis log (Speed over water: Compliant with IEC61162)
2AXG : 2-axis log (Speed over ground: Compliant with IEC61162)
GPS : GPS (Compliant with IEC61162)
7.1.7 Setting of True Bearing Value
If GYRO I/F is used to input a gyro signal, the true bearing value indicated by the master gyro does not
match the value indicated by the radar equipment only in a rare case. In this case, perform the following
procedure to adjust the true bearing value of the radar equipment to the value of the master gyro.
Procedures 1. Press the [RADAR MENU] key twice.
2. Open the GYRO Setting menu by performing the following menu
operation.
4. NAV Equipment Setting
→ 1. GYRO Setting
3. Input the master gyro value to the value input screen. (For inputs to
the value input screen, refer to Section 3.3.4.)
4. Move the cursor onto the ENT button, and press the [ENT] key.
7-7
To Next Page
