5.1 Preparation
yy
yyy
Operation of AUTO Mode
As shown below, the AUTO mode performs operation in accordance with the object at the cursor position
when the [ENT] key is pressed.
Object at Cursor Position Operation
None Acquires a target.
EBL Performs EBL operation.
VRM Performs VRM operation.
Intersection point of EBL and VRM Performs EBL operation and VRM operation at the same time.
Parallel index line (PI) Operates the parallel index line.
Tracked target Displays the numeric data of the tracked target.
Tracked target with numeric data displayed Hides the numeric data.
Sleeping AIS target Activates the AIS target.
Activated AIS target Displays the AIS target information.
AIS target with numeric data displayed Hides the AIS target information.
Automatic acquisition / activation zone Operates the automatic acquisition / activation zone.
Sector radar alarm zone Operates the sector radar alarm zone.
AIS filter zone Operates the AIS filter zone.
5
5-12
