[III] Reception Sentence Setting (RX Sentence)
Set signal sentences to be received from sensors.
The system is factory-set for using all sentences.
To receive only specified sentences, select No Use for sentences which are not necessary.
Procedures 1. Open the Serviceman Menu.
2. Open the RX Sentence menu by performing the following menu
operation.
2. Installation Menu
→ 5. COM Port Setting
→ 3. RX Sentence
3. Select the sentences to be used by the sensors to be set.
Selection value: Use or Not Use can be selected for each sentence.
1. GPS(LL/COG/SOG) > : GGA/RMC/RMA/GNS/GLL/VTG
2. GPS(WPT/Time) > : GGA/RMC/RMB/BWC/BWR/ZDA
3. Depth > : DPT/DBK/DBT/DBS
4. Wind > : MWV/MWD
5. Current > :
Data Set Number : 0-9. Set the number of the sentence to be used by
Data Set Number. (Initial value All)
Layer A : 0-999. Set the number of the sentence to be used
with layer A by Layer Number. (default value : 3)
Layer B : 0-999. Set the number of the sentence to be used
with layer B by Layer Number. (default value : 4)
Layer C : 0-999. Set the number of the sentence to be used
with layer C by Layer Number. (default value : 5)
6. Autopilot : APB (default value : Not Use)
7-13
