JMA-9100/7100 Installation Manual > 4.INITIAL SETTING > 4.1 GYRO INTERFACE SETTING
4－5
4
4.1.2 NMEA Input setting
Sentences HDT and THS are effective.
The baud rate can be selected from either 4800, 9600, 19200, or 38400.
Data must be updated within 60 ms. The sensor which outputs updated data with
an interval longer than 60 ms cannot be used. (An error is indicated)
Procedures
1) To activate NMEA Input, set S2-6 at [ON].
2) Set the baud rate for S2-7,8 in accordance with the heading sensor signal
output specifications.
3) Make sure that the short plug of TB108 and 109 is located in the opposite
position of the standard position printed on the board. If it is inserted in the
default position (1-2), change it to the position between 2 and 3 as shown in
図
4-3 "TB108,TB109."
Table4-2： Gyro and Log Select Switches (S2 Dip Switch)
S2 SETTING TABLE 1 2 3 4 5 6 7 8
OTHER SETTING
LOG ALARM ON
OFF
GYRO SIMULATOR ON
OFF
LOG SIMULATOR ON
OFF
N.A.
Don't care
any
GYRO ALARM TIME 5s ON
0.2s OFF
HEADING SENSOR SOURCE NMEA(HDT/THS) ON
GYRO SIGNAL OFF
NMEA BAUDRATE SETTING 4800 OFF OFF
9600 ON OFF
19200 OFF ON
38400 ON ON
To Next Page
