JMA-9100/7100 Installation Manual > 4.INITIAL SETTING > 4.2 TUNE ADJUSTMENT
47
4
4.2 TUNE ADJUSTMENT
Tune control of the transmitter and the receiver is conducted.
This adjustment is made at the installation and the replacement of magnetron.
Procedures
1) Open the [Service Man Menu] screen.
2) Open the [1.Tune Adjustment] screen according to the operation shown
below.
For how to input values on the value input screen, see Section 3.3.4 in the
instruction manual.
3) Operate the + or - button to set the tune adjustment value so that the tune
bar at the upper left on the screen is maximized.
4) Left-click the ENT button to confirm the value.
1. Adjust Menu
