JMA-9100/7100 Installation Manual > 4.INITIAL SETTING > 4.6 TRUE BEARING SETTING
4－11
4
4.6 TRUE BEARING SETTING
When a gyro signal is inputted by using GYRO I/F, there is a rare case in which
the true bearing value indicated by the master gyro does not match the true
bearing value indicated by this apparatus.
In that case, make adjustments so that the true bearing value of this apparatus
matches the true bearing value indicated by the master gyro.
Procedures
1) Open the [1.GYRO Setting] screen according to the operation shown below.
2) Enter the value indicated by the master gyro on the value input screen.
For how to input values on the value input screen, see Section 3.3.4 in the
instruction manual.
Main Menu
→
6. NAV Equipment Setting
→
1. GYRO Setting
To Next Page
