JMA-9100/7100 Installation Manual > 3.INSTALLATION OF DISPLAY UNIT > 3.2 INSTALLATION OF AC-DC CONVERTER NBA-5135
3.2 INSTALLATION OF AC-DC
CONVERTER NBA-5135
When an scanner unit of either NKE-2103-6, NKE-2103-6HS, or NKE-2254-6HS
is used, an AC/DC converter NBA-5135 is necessary.
The installation method differs depending on whether the display unit is a model
of the JMA-9100 series or the JMA-7100 series, or self-standing or desktop.
3.2.1 NBA-5135 Packing List
* Applicable fuse ST6-10AN15ZFCA00053
(Included in spare parts 7ZXRD0025)
General model: JMA-9110-6XA, JMA-9110-6XAH, JMA-9122-6XAH
JMA-7110-6XA, JMA-7110-6XAH, JMA-7122-6XAH)
Table 3 - 1 NBA-5135 Packing List
No.
Partname/部品名
Pcs
Code/コード Remark/備考
1
GUARD/ガード
1 MTB389784

2 AC/DC CONVERTER UNIT
AC/DC コンバーター
1 MANBA5087
NBA-5135)
FUSE ST6-10AN
(5ZFCA00053)
3
CABLE/ケーブル
1 7ZCRD1344A
W408 BLACK 3core,3m
4
CABLE/ケーブル
1 7ZCRD1343A
W407 GRAY 2core,3m
5
CABLE/ケーブル
1 7ZCRD1342A
W406 GRAY 2core,0.6m
6
TERMINAL BLOCK/端子台
1 MDH67A-3P TB401
7
SEMS SCREWS/なべ小ねじ
2 NB3X8FE for GUARD
8
SEMS SCREWS/なべ小ねじ
4 NC4X14FE for TERMINAL BLOCK
9
BOLTS/十字穴付六角ボルト
5 BRTG08964 for AC/DC CONVERTER UNIT
10
PACKING LIST/ パッキングリスト
1 MTZ303786
