JMA-9100/7100 Installation Manual > 5.OPTION UNIT > 5.2 INSTALLATION OF POWER CONTROL UNIT
5ļ¼61
5
Fig 5-60: NQE-3167 cable entrance
Fig 5-61: NQE-3167 terminal block
Securely ground the included earth plate to the hull's earth.
J2
EARTH
PLATE
TB1
TB3
TB2
