3.3 PREPARATION
.
..
After the colors are adjusted, the following menu will appear.
The menu display after adjustment shows the colors set for the indiviual items.
1
Press
.
The Sub2 Menu will reappear.
2
Press
.
The Sub2 Menu will be closed.
0
0
Exit
5.CHARACTER
6.DIAL
SUB2 MENU
COLOR
2.SYSTEM
3.OUTER PPI
4.INNER PPI
1.DAY/NIGHT
0.
EXIT
1. DAY1
1. WHITE
1. WHITE
1. BLUE1
7.ECHO
1. YELLOW
8.TRAILS
1. SKY
9.OWN TRACK
1. SKY
1. BLACK
1. BLACK
100
102
