8
8 – 12
.
...
....
8.1 FUNCTION CHECK
2 Press .
The TEST Menu will be closed.
……8.1.2 List of Alarms and other Indications ………………………
Table 8.2 List of Gyro Alarms
Table 8.3 List of ARPA Alarms
Table 8.4 List of Operational Error Messages and Warnings
Message Description
SET GYRO Requires initialization of NSK or setting of initial values for gyro.
TM RESET
Own ship’s position has reached at approx. 60% of the radar
PPI radius in the TM mode.
POSN RST Change the latitude and longitude sentence.
Message Description
CPA/TCPA CPA/TCPA of a target (ARPA)
GZ A target approaching own ship exists in a guard zone.
LOST A target under acquisition can not be tracked.
Message Description
OUT OF RANGE Tried to create a guard zone outside the specified range.
CHANGE RANGE The range is set outside the specified in creating a guard zone.
MAX POINT Tried to enter navigation information beyond the specified.
CAN’T TRANSMIT
Tried to transmit within 1 second after standby or when
the transmitter-receiver has any trouble.
MAX MARK Tried to enter more than 20 plot marks.
CAN’T USE
Key in with the [ + ] or [ - ] at any place where only a numerical
value can be entered.
CAN’T CHANGE Tried to make any operation that cannot be changed.
NO GYRO DATA Any operation requiring Gyro data was made without it.
INVALID DATA Tried to enter any data beyond its range.
NO POSITION DATA Any operation requiring position data was made without it.
CHG REL VECTOR Tried to display a CPA ring in TRUE mode.
MAX TARGET The maximum number of targets (50 targets) is under acquisition.
SELECT STRAIGHT The operator set PM to ON without selecting straight.
NOT ALLOWED Improper operation
