3 – 53
……Display Own Ship’s Track OWN TRACK ………………………
In the case that Any Navigation Equipment is Connected to This System
Own ship’s track data is sent from the navigation equipment and up to 1024 points of data can
be recorded and displayed. The data storage time interval can be set in 4 levels 3 min (equal
to the length of own ship’s track for 3 minutes), 10 min, 15 min and 30 min.
1 Press .
The Main Menu will appear.
2 Press .
The Sub1 Menu will appear.
3 Press .
The TRACK Menu will appear.
4 Press .
“ON” in “1.TRACK” will be set and own ship’s past track
originated from its current position will appear. The current storage time interval will appear at
lower left on the radar display.
1 Press .
“OFF” in “1.TRACK” will be set and own ship’s track and the storage time interval will
disappear.
To Next Page
