3 – 56
3
3.4 BASIC OPERATIONS
.
..
……Marking MARK ……………………………………………………
A maximum of 20 marks can be displayed at arbitrary positions on the radar video.
A mark created on the display holds the latitude and longitude.
[
11
] Plotting Marks
1 Press .
will appear in the CURSOR ( ) at the upper right of the radar display.
2 Put the cross cursor mark [ + ] on the position where the []mark is inserted.
3 Press or trackball section left button.
The cross cursor mark [ + ] will be changed into the [ ] mark and fixed on the radar display.
When entering more [ ] marks, repeat the procedures from step 2. Up to 20 marks can be
entered.
Note: If more than 20 marks are created, the oldest mark is cleared and the newly created
mark is displayed.
[
22
] Clearing Marks
1 Press .
will appear in the CURSOR ( ) at the upper right of the radar display.
2 Put the cross cursor mark [ + ] on the position where the [ ] mark is inserted.
3 Press or trackball section right button.
The [ ] mark will disappear. When clearing another [ ] mark, repeat the procedure from step
2.
When clearing all [ ] marks, press and continue to depress for about 2
seconds.
