8 – 13
Note:
1) An error message and a warning will appear at the lower right of the radar display.
Table 8.5 List of Interswitch Alarms and Messages
Message Description
MASTER RANGE CHG
Tried to change the master range.
ALREADY SELECTED
Selected the already selected pattern.
ISW END! The switchover of the Interswitch ended normally.
ISW BUSY! Access to the ISW menu was made during interswitching.
MTR ST-BY! The master MTR is in the standby mode.
ISW STRAIGHT
Failed in straight connection when the Interswitch system stops
operating.
ISW STAND-BY! The Interswitch recovered normally.
ISW TIME OUT Communication error ocurred between interswitch and display.
ISW ERROR! The interswitch is disabled.
Position of message or warning indication
