Page #257 background image
8 – 14
8.1 FUNCTION CHECK
.
...
....
8
Table 8.6 List of System Alarms
Message Description
MTR (AZI) Bearing signal error
MTR (HL) Ship’s heading line signal error
MTR (MHV) Modulator’s high voltage error
MTR (DATA) Communications error with the transmitter-receiver unit
MTR (HEATER) Magnetron heater voltage is abnormal
MRT (REVERSE) Antenna rotation is reversed
MTR STATUS Transceiver status error
SSW OFF The safety switch is OFF during switchover of the scanners
NSK (GYRO) Gyro signal OFF
ISW (DATA) Communications error with the interswitch
LOG Log signal OFF
NAV (DATA) Data from navigation equipment OFF
DLOG 2-axis log signal OFF
ARPA (DATA) Communications error with the ARPA unit
NSK (DATA) Communications error with the NSK unit
VIDEO Radar video OFF
TRIGGER Trigger signal OFF
FAN1 Fan alarm 1
FAN2 Fan alarm 2
PROC (DATA) Signal processing circuit error
SERI (DATA) Serial interface circuit error
LAN (DATA) LAN I/F circuit error
232C (DATA) RS-232C communications error
MTR (VIB) Abnormal scanner vibrations
MTR (TMP) Abnormal scanner temperature
COM1 Com port1 failure
COM2 Com port2 failure
COM3 Com port3 failure
COM4 Com port4 failure
COM5 Com port5 failure
COM6 Com port6 failure
COM7 Com port7 failure
COM8 Com port8 failure
COM9 Com port9 failure
COM10 Com port10 failure
MAG (HDG) Data from Mag compass have been cut off
PROC (AZI) Bearing pulse is abnormal
