9-7 Section 9 Route Planning
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
[2] [Distance calculation mode]
Set a method for calculating a distance between WPTs.
When [Straight] is selected, a distance between WPTs is calculated with a straight line
When [with Turn] is selected, a distance between WPTs is calculated based on the expected route.
[3] [Monitoring]
Set a route monitoring method.
When [Wheel-over line] (steering line) is selected, monitoring is performed by using Wheel-over line
(WOL) along each WPT.
When [Arrival circle] is selected, monitoring is performed by using the arrival circle along each WPT.
Arrival circle
Wheel over line
WPT 1 WPT 2
WPT 3
WPT 1 WPT 2
WPT 3
