KE2000 Installation Manual
37
The interface circuit diagrams of the READY OUT (IN) and BOARD AVAILABLE signals
are shown in the Figure below.
These signals conform to the SMEMA standard.
Fig 13-1
GND24V
+
24
3.3K 1/4W
READY OUT
BOAD AVAILABLE IN
READY OUT
BOAD AVAILABLE IN
N.C.
1
2
3
4
5
14
READY IN
BOAD AVAILABLE OUT
READY IN
BOAD AVAILABLE OUT
N.C.
1
2
3
4
5
14
24
3.3K 1/4W
+
GND24V
