KE2000 Installation Manual
41
14-3. TR-6SN and TR-6DN
Mount the TR-6SN and TR-6DN on the right of the main unit. The positional relationship
should be as shown in Figure 14-3-1. (Unit: mm)
Fig 14-3-1. Outside view of TR-6SN and TR-6DN mounting portions
WARNING
WARNINGWARNING
WARNING
To prevent the body from injury which can be caused by
accidental activation of the machine , cut off the power to
the machine before starting to work.
Rear of the main unit
Home Position (Origin position)
To Next Page
