JUKI KE-2000 Series - Basic Configuration and Component Identification; KE-2010;2020;2040 Configuration Details

KE2000 Installation Manual
1
1. Basic configuration and name of each part
1-1. KE-2010/2020/2040
1-1-1. Standard Machine
Fig.1-1-1-1
Front view
Fig.1-1-1-2
Right side view
1-1-2. ＣＥ Machine
Fig.1-1-2-1
Front view
Fig.1-1-2-2
Right side view
(1) Vision monitor (5) Track ball
(2) LCD panel (6) Signal light
(3) HOD (Handheld Operating Device) unit (7) Main switch
(4) Keyboard (8) No-fuse circuit breaker
