KE2000 Installation Manual

14-2. TR-4SN

Mount the TR-4SN on the rear of the main unit. The positional relationship should be as

shown in Figure 14-2-1. (Unit: mm)

Fig 14-2-1.

Outside view of TR-4SN mounting portions

Front of the main unit

Rear of the main unit

WARNING

WARNINGWARNING

WARNING

To prevent the body from injury which can be

caused by accidental activation of the machine , cut

off the

ower to the machine before startin

to work.

Home position

857 (common

for M, L, E)

MTC

pick

osition
