KE2000 Installation Manual
42
14-4. TR-5SN and TR-5DN
Mount the TR-6SN and TR-6DN on the rear of the main unit. The positional relationship
should be as shown in Figure 14-4-1. (Unit: mm)
Fig 14-4-1. Outside view of TR-5SN and TR-5DN mounting portions
※When installing the TR5SN/5DN to the main unit, detach the handle on the main unit
rear cover first.
WARNING
WARNINGWARNING
WARNING
To prevent the body from injury which can be caused by
accidental activation of the machine , cut off the power to
the machine before starting to work.
