JUKI MO-2800 - TWA (Tweak Width Adjustment)

14
Adjustments and settings
TWA (Tweak Width Adjustment)
Overlocking width is set in conjunction with the adjustment of the lower
knife position. It is also possible to nely adjust the overlocking width
separately.
A To decrease the overlocking width
B To increase the overlocking width
C The material edge does not reach the seam. (There are gaps in the
material edge within the seam)
→ Turn the TWA knob in the direction of decreasing the overlocking
width.
D The material edge projects from the seam or curls.
→ Turn the TWA knob in the direction of increasing the overlocking
width.
* If the excess of thread or material curling cannot be corrected with
the "lower knife position" or "overlocking width adjustment", or if
you want to nely adjust the texture of seam, adjust the upper/lower
looper thread tension dial.
8
A
注意
C
D
8
A
注意
A
B
