JUKI MO-2800 - Technical Data

36
Stitch choice Over lock 2 needles, 2 loopers: 4 thread overlock with integrated safety seam
1 needle, 2 loopers: 3 thread overlock, atlock roll hem
1 needle, 1 looper: 2 thread overlock, atlock roll hem
2 needles, 1 looper: 3 thread super stretch
Needle system SCHMETZ 130/705 H or JLx2
Seam width 3.5-5.5 mm (3/2 thread overlock)
5.5-7.5 mm (4 thread overlock / 3/2 thread overlock / 3 thread super stretch)
Stitch length 0.7-4 mm
Di󰀨erential feed No puckering 0.7 - N
No waving or uting in knits N - 2
Presser foot lifter 6 mm
Handwheel rotates forwards
Sewing speed Up to 1500 sti/min
Weight 10.0 kg
Dimensions 350 (W) x 310 (D) x 340 (H) mm
Foot control model No. YC-482 (USA and Canada only)
YC-483N (220-240V)
We reserve the right to make changes in the interest of technical progress.
Technical data
