JUKI SC-920 Engineer's Manual

– 57 –
9. CONNECTOR CONNECTION DIAGRAM
(1) Solenoid for machine head
(2) Solenoid for lifting presser foot
1
2
FLD 1
FLCOM 2
FL
(Presser foot lifter)
Approx 5.4Ω
CN37
DDL-9000B-DS
CN36
TRM (Thread trimming)
Approx 7.5 Ω
BT (Touch back)
Approx 6.5 Ω
WP (Wiper)
Approx 8.5 Ω
BT SW
Touch back switch
TRMD 1
TRM COM 8
BTD 6
BT COM 13
WPD 2
WP COM 9
TL SUB 7
TL SUB COM 14
CON 4
CON COM 11
BTSW 5
BT RTN 12
3
HADE SEL
（DDL-9000B-DS）
FG 10
DS
8 9 10 11 12 13 14
1234567

JUKI SC-920 Specifications

General

Stitch Type	Lockstitch
Thread Trimmer	Automatic
Work Clamp	Pneumatic
Power Consumption	550W
Motor Type	AC servo motor
Hook	Full rotary hook
