– 1 –
1. SPECIFICATIONS
Supply voltage Single phase 100 to 120V 3-phase 200 to 240V Single phase 200 to 240V
zH 06 / zH 05zH 06 / zH 05zH 06 / zH 05ycneuqerF
Operating temperature range Temperature : 0 to 40°C Temperature : 0 to 40°C Temperature : 0 to 40°C
Operating humidity range Humidity : 90% or less Humidity : 90% or less Humidity : 90% or less
Power consumption 320VA 320VA 320VA
Mass 3kg 3kg 3kg
2. OUTLINE
(1) Features
1) Voltage changeover function of single phase 100 to 120V/3-phase 200 to 240V is provided.
The control box with voltage changeover function can be used either for single phase 100 to 120V or for 3-
phase 200 to 240V by replacing the power cord up to the power switch and changing the voltage changeover
connector inside the box.
In addition, it can be used for single phase 200 to 240V.
2) By using IP-110F, CP-180 the sewing management information such as output display, etc. can be used.
3) The conventional JUKI optional devices can be used without any adjustment.
However, when AE (bobbin thread remaining amount detection device) is used, it is necessary to separately
purchase the optional circuit board.
4) By using the flash ROM for CPU, the future version-up can be adapted.
5) The SC-920 control box can be used for the (belt) drive system machine head by connecting the DD
(direct-drive) system machine head and the small-sized motor unit (M-92).
