* Do not change the set values with asterisk (
*
) mark as they are functions for maintenance. If the standard set value set at the
time of delivery is changed, it is in danger of causing the machine to be broken or the performance to be deteriorated.
(10) Function setting list
No
Item Description
Setting range
Indication of function setting
Ref. page
1 Soft start
function
The number of stitches to be sewn at a low speed when the soft-
start function is used at the start of sewing.
0 : The function is not selected.
1 to 9 : The number of stitches to be sewn under the soft-
start mode.
0 to 9
(Stitches)
1
0
44
2 Material end
sensor function
Material end sensor function (to be used only with CP-18).
0 : Material end detection function is not operative.
1 : After detecting material end, the specified number of
stitches (No. 4) will be sewn, and the sewing machine will
stop.
0/1
2
0
44
3
Thread trimming
function by
material end
sensor
Thread trimming function by material end sensor (to be used
only with CP-18).
0 : Automatic thread trimming function after detection of ma-
terial end is not operative.
1 : After detecting material end, the specified number of
stitches (No. 4) will be sewn, and the sewing machine will
stop and perform automatic thread trimming.
0/1
3
0
44
4 Number of
stitches for
material end
sensor
Number of stitches for material end sensor (to be used only with
CP-18).
Number of stitches from detection of material end to stop of the
sewing machine.
0 to 19
(Stitches)
4
5
44
5 Flicker reducing
function
Flicker reducing function
0 : Flicker reducing function is not operative.
1 : Flicker reducing function is effective
0/1
5
0
44
6 Bobbin thread
counting
function
Bobbin thread counting function
0 : Bobbin thread counting function is not operative.
1 : Bobbin thread counting function is operative.
0/1
6
1
44,48
*
7 Unit of bobbin
thread counting
down
Unit of bobbin thread counting down
0 : 1 Count/10 stitches
1 : 1 Count/15 stitches
2 : 1 Count/20 stitches
3 : 1 Count/thread trimming
0 to 3
7
0
*
8 Number of
rotation of
reverse feed
stitching
Sewing speed of reverse feed stitching
150 to 3,000
(sti/min)
8
1 9 0 0
9 Thread
trimming
prohibiting
function
Thread trimming prohibiting function
(to be used only with CP-18)
.
0 : Thread trimming prohibiting function is not operative.
1 : Thread trimming is prohibited.
(Output of solenoid is prohibited. : Thread trimmer and wiper)
0/1
9
0
44
10 Setting of
needle bar stop
position when
the sewing
machine stops.
Position of needle bar is specified when the sewing machine
stops.
0 : Predetermined lowest position
1 : Predetermined highest position
0/1
1 0
0
44
11 Operation
confirmation
sound for
operation panel
Operation confirmation sound for operation panel
0 : Operation confirmation sound is not generated
1 : Operation confirmation sound is generated.
0/1
1 1
1
44
12 Optinal switch
function
selection
Switching of function of optional switch.
Refter to
“5.-(11) Detailed explanation of selection of func-
tions”
1 2
45
*
13 Function of
prohibiting start
of the sewing
machine by
bobbin thread
counter
Function of prohibiting start of the sewing machine by bobbin thread counting
0 : When counting is out (-1 or less) Function of prohibiting
start of the sewing machine is not operative.
1 : When counting is out (-1 or less) Function of prohibiting
start of the sewing machine after thread trimming is op-
erative.
2 : When counting is out (-1 or less), the sewing machine
stops once. Function of prohibiting start of the sewing
machine after thread trimming is operative.
0 to 2
1 3
0
14 Sewing counter Counting function of sewing (number of completion of process)
0 : Sewing counter function is not operative.
1 : Sewing counter function is operative. (Every time thread
trimming is performed)
2 : With the sewing counting switch input function
0 to 2
1 4
1
48
15 Thread wiping
function after
thread trimming
Thread wiping operation after thread trimming is specified.
0 : Thread wiping is not carried out after thread trimming
1 : Thread wiping is carried out after thread trimming
0/1
1 5
1
21 Function of
neutral presser
lifting
Function of lifting presser foot when the pedal is in neutral posi-
tion.
0 : Function of neutral automatic presser lifting is not opera-
tive.
1 : Selection of function of neutral presser lifting.
0/1
2 1
0
48
