2 Technical description
These operating instructions do not take into account all possible applications or product variations.
If you are looking for notes on your specific application, please contact the main factory.
If you need more detailed technical information on a specific instrument, please ask for the corresponding
Data Sheet.
Phone (+49) 661 6003-0
The instrument version of your pressure transmitter can be seen from the instrument label.
3 Installation
3.1 Safety note
Type Data Sheet Type Data Sheet Type Data Sheet
dTRANS p31 40.2050 4AD-30 40.4354 4364 40.4364
4327 40.4327 4355 40.4355 dTRANS p30 40.4366
4341 40.4341 4359 40.4359 4380 40.4380
4AP-30 40.4353 4362 40.4362
(1)
(2)
(3)
(4)
Type code
Range
Supply
Serial number
(5)
(6)
(7)
Part number
Output
Manufacturing date
(Year and week)
The device does not meet the requirements for a „Components with a safety function“ accord-
ing to the Pressure Equipment Directive 97 / 23 / EC.
For hazardous substances, such as oxygen, acetylene, combustible and toxic materials, as well
as in refrigeration equipment, pressure containers etc., the relevant regulations must be fol-
lowed!
Ignoring these regulations can result in injury or damage to persons or property.
Only properly qualified personnel may work on this equipment.
404366/000
0...0,25 bar
DC 12...30 V 4...20 mA
F.-Nr.: 0012345601005120123
(1)
(2)
(3)
(4)
(5)
}
(6)
Made in Germany
MIDAS
TN 12345678
(1)
(2)
(3)
(4)
(7)
