Jungheinrich EJC B14 User Manual

17
03.11 EN
3.3 Standard mast version EJC B14
3.4 Standard mast version EJC B16
EJC B14 EJC B16
c Load centre distance 600 600 mm
x Load distance 667 667 mm
y Wheelbase 1409 1409 mm
l1 Length with fork length 1150 mm 2050 2050 mm
l2 Fork length
including fork shank
900 900 mm
b4 Dimension between the wheel
arms (adjustable)
900 - 1350 900 - 1350 mm
b5 Width across forks 316 - 900 316 - 900 mm
m2 Ground clearance centre
wheelbase
30 30 mm
Ast Working width 1000x1200
crosswise 1)
2162 2162 mm
Ast Working aisle width for
pallet 800x1200 longit. 1)
2362 2362 mm
Wa Turning radius
lowered / raised
1629 1629 mm
1) wit DZ mast: +4 mm
Description
Telescopic mast
(ZT)
Twin-reach mast
(ZZ)
Triplex Mast (DZ)
h1 Height 1) 1700 - 2600 1700 - 2600 1800 - 2250 mm
h2 Free lift 2) 100 - - mm
h3 Lift 2500 - 4300 2500 - 4300 4000 - 5350 mm
h4 Max. height 4) 3060 - 4860 3060 - 4860 4560 - 5910 mm
h5 Free lift 3) 5) - 1140 - 2040 1240 - 1690 mm
Description
Telescopic mast
(ZT)
Twin-reach mast
(ZZ)
Triplex Mast (DZ)
h1 Height 1) 1700 - 2600 1700 - 2600 1800 - 2250 mm
h2 Free lift 2) 100 - - mm
h3 Lift 2400 - 4200 2400 - 4200 3900 - 5250 mm
h4 Max. height 4) 2960 - 4760 2960 - 4760 4460 - 5810 mm
h5 Free lift 3) 5) - 1140 - 2040 1240 - 1690 mm
17
03.11 EN
3.3 Standard mast version EJC B14
3.4 Standard mast version EJC B16
EJC B14 EJC B16
c Load centre distance 600 600 mm
x Load distance 667 667 mm
y Wheelbase 1409 1409 mm
l1 Length with fork length 1150 mm 2050 2050 mm
l2 Fork length
including fork shank
900 900 mm
b4 Dimension between the wheel
arms (adjustable)
900 - 1350 900 - 1350 mm
b5 Width across forks 316 - 900 316 - 900 mm
m2 Ground clearance centre
wheelbase
30 30 mm
Ast Working width 1000x1200
crosswise 1)
2162 2162 mm
Ast Working aisle width for
pallet 800x1200 longit. 1)
2362 2362 mm
Wa Turning radius
lowered / raised
1629 1629 mm
1) wit DZ mast: +4 mm
Description
Telescopic mast
(ZT)
Twin-reach mast
(ZZ)
Triplex Mast (DZ)
h1 Height 1) 1700 - 2600 1700 - 2600 1800 - 2250 mm
h2 Free lift 2) 100 - - mm
h3 Lift 2500 - 4300 2500 - 4300 4000 - 5350 mm
h4 Max. height 4) 3060 - 4860 3060 - 4860 4560 - 5910 mm
h5 Free lift 3) 5) - 1140 - 2040 1240 - 1690 mm
Description
Telescopic mast
(ZT)
Twin-reach mast
(ZZ)
Triplex Mast (DZ)
h1 Height 1) 1700 - 2600 1700 - 2600 1800 - 2250 mm
h2 Free lift 2) 100 - - mm
h3 Lift 2400 - 4200 2400 - 4200 3900 - 5250 mm
h4 Max. height 4) 2960 - 4760 2960 - 4760 4460 - 5810 mm
h5 Free lift 3) 5) - 1140 - 2040 1240 - 1690 mm
