Jungheinrich EJC B14 User Manual

39
03.11 EN
Ite
m
Control / Display EJC B14 EJC B16 Function
2 Slow travel button tt– If the tiller is in the upper
braking zone, braking can be
overridden by pressing the
switch, and the truck can
move at reduced speed
(slow travel).
3 Travel switch ttControls the travel direction
and speed.
5 Collision safety switch ttSafety function
– When applied the truck
travels for approx. 3 seconds
in the fork direction. The
parking brake then applies.
The truck remains switched
off until the travel switch is
set to neutral.
7 Tiller tt– Used to steer and brake the
truck.
8 Emergency Disconnect
(battery switch)
ttDisconnects the battery supply
– All electronic functions are
cut out and the truck
decelerates.
9 Battery charge /
discharge indicator
tt– Indicates the charge/
discharge status of the
battery.
CanDis ooDisplay instrument for:
– Battery charge status
– Service hours
– Warning alarm
– Parameter settings
10 CanCode ooReplaces the key switch
– Activates the truck by
entering the relevant code
– Travel program selection
– Code setting
– Parameter setting
12 Key switch and key tt– Activates the truck by
applying the control voltage
– Removing the key prevents
the truck from being
switched on by unauthorized
personnel.
14 Document storage
compartment
oo– Used to store documents.
47 Warning signal (horn)
button
tt– Activates a warning signal.
39
03.11 EN
Ite
m
Control / Display EJC B14 EJC B16 Function
2 Slow travel button tt– If the tiller is in the upper
braking zone, braking can be
overridden by pressing the
switch, and the truck can
move at reduced speed
(slow travel).
3 Travel switch ttControls the travel direction
and speed.
5 Collision safety switch ttSafety function
– When applied the truck
travels for approx. 3 seconds
in the fork direction. The
parking brake then applies.
The truck remains switched
off until the travel switch is
set to neutral.
7 Tiller tt– Used to steer and brake the
truck.
8 Emergency Disconnect
(battery switch)
ttDisconnects the battery supply
– All electronic functions are
cut out and the truck
decelerates.
9 Battery charge /
discharge indicator
tt– Indicates the charge/
discharge status of the
battery.
CanDis ooDisplay instrument for:
– Battery charge status
– Service hours
– Warning alarm
– Parameter settings
10 CanCode ooReplaces the key switch
– Activates the truck by
entering the relevant code
– Travel program selection
– Code setting
– Parameter setting
12 Key switch and key tt– Activates the truck by
applying the control voltage
– Removing the key prevents
the truck from being
switched on by unauthorized
personnel.
14 Document storage
compartment
oo– Used to store documents.
47 Warning signal (horn)
button
tt– Activates a warning signal.

Jungheinrich EJC B14 Specifications

General

Brand	Jungheinrich
Model	EJC B14
Category	Trucks
Language	English
