0708.GB

B 4

Electrical System:

Service laptop connection interface:

– Configures all key truck data (lift limit damping, lift cutout, retardation and

acceleration patterns, cut-outs, etc.) rapidly and reliably.

– Reads off the error log to analyse fault causes.

– Simulates and analyses program operations.

– Simple function extention by releasing code numbers.

The controller is fitted with a CAN Bus and a constantly measuring sensor system.

The controller provide smooth starting and braking of the load in all limit positions

through lift limit and intermediate dampers.

Highly efficient threephase technology with energy retention for the traction and lift

motors provides high travel and lift speeds and better use of energy.

The 48 volt MOSFET threephase controller provides a smooth start to each

movement.

For drive battery options see chapter D.

3 Standard Version Specifications

Technical data specified in accordance with VDI 2198.

Technical modifications and additions reserved.

3.1 Performance data

Description EKS 310k EKS 310

Q Capacity (where C = 600 mm) 1000 1000 kg

c Load centre of gravity distance 400 600 mm

Travel speed without load (RG) 9 10,5 km/h

Travel speed with load (RG) 8,8 10,0 km/h

Travel speed without load (IG) 7,0 9,0 km/h

Travel speed with load (IG) 6,8 8,8 km/h

Lift speed without load 0,22 0,37 m/s

Lift speed with load 0,18 0,32 m/s

Lowering speed with load 0,32 0,37 m/s

Lowering speed without load 0,3 0,34 m/s
