4.1 Truck data plate
For queries regarding the truck or spare part orders, please quote the serial number
(20).
4.2 Capacity
The plate (8) gives the capacity (Q in kg) of the truck as a function of the load centre
of gravity distance (D in mm) and lift height (H in mm) in tabular form.
Item Description Item Description
19 Type 25 Manufacturer
20 Serial no. 26 Min./Max. battery weight (kg)
21 Rated capacity (kg) 27 Drive output (kw)
22 Battery voltage (V) 28 Load centre of gravity (mm)
23 Net weight w.o. battery (kg) 29 Year of manufacture
24 Manufacturer’s logo 30 Option
25
24
26
23
27
22
28
21
29
20
30
19
8
D (mm)
h3 (mm) Q (kg)
