0301.GB

E 2

2 Description of the operating controls and indicators

Item Control or indicator Function

1 Collision protection button t The truck moves away from the ope-

rator.

2 Controller t Controls the direction and speed of

travel.

3 Button “Lift load lifting device” t For lifting the load lifting device.

4 Button “Lower load lifting de-

vice”

t For lowering the load lifting device.

5 Button “Horn” t Triggers an acoustic signal.

6 Button - Manoeuvering t If the control shaft is in the upper bra-

king range, the braking action can be

overriden by a button and the truck

can be moved with decreased speed

(manoeuvering).

7 Integrated charger

(incl. safety cut-out)

The battery is charged when the

mains plug is plugged into an electric

outlet.

8 Key swith with integrated

emergency-off button

t For switching the control current on

and off. Removing the key prevents

the truck from being switched on by

unauthorised persons.

9 Charging connection for 24 V

lorry chargind cable (o)

o Charging battery by plugging in the

24 V lorry charging cable.

10 Discahrge control LED

(discharge indicator)

t Shows the charging condition of the

battery (refer to chapter D).

t = Standard equipment o = Optional equipment
