Jungheinrich HC 110 Operator's Manual

1004.GB
B 4
3 Standard Version Specifications
Z
Technical specification details in accordance with VDI 2198. Technical modifications
and additions reserved.
3.1 Performance data for standard trucks
3.2 Dimensions
F
The battery size must be adhered to for the duplex mast, as the battery weight must
be present in the truck to act as a counterweight.
Description HC
Q Rated capacity 1000 kg
C Load centre of gravity distance 600 mm
Lift speed (lift) w / w.o. load 8 / 10 cm/sec
Lift speed (lower) w / w.o. load 27 / 15 cm/sec
Description
Lift height
HC 110
1600
HC 110
2500
HC 110
3000
h
1
Height 2100 1850 2100 mm
h
3
Lift 1600 2500 3000 mm
h
4
Mast height extended 2100 3055 3550 mm
h
13
Lowered height 90 90 90 mm
y Wheel base 1335 1335 1335 mm
s/e/l Fork tine dimensions 21/170/1070 21/170/1070 21/170/1070 mm
l
1
Overall length 1755 1755 1755 mm
l
2
Headlength 685 685 685 mm
b
1
Truck width 722 722 722 mm
b
5
Outer load fork distance 580 580 580 mm
b
11
Track width, rear 410 410 410 mm
Ast Working Aisle Width
800x1200 traverse
2175 2175 2175 mm
Ast Working Aisle Width
800x1200 longit.
2145 2145 2145 mm
Lift motor, output where
s
3
10%
1,6 1,6 1,6 kW
Battery voltage, rated
capacity k
5
12/70 12/100 12/100 V / Ah
Battery weight 24 38 38 kg
1004.GB
B 4
3 Standard Version Specifications
Z
Technical specification details in accordance with VDI 2198. Technical modifications
and additions reserved.
3.1 Performance data for standard trucks
3.2 Dimensions
F
The battery size must be adhered to for the duplex mast, as the battery weight must
be present in the truck to act as a counterweight.
Description HC
Q Rated capacity 1000 kg
C Load centre of gravity distance 600 mm
Lift speed (lift) w / w.o. load 8 / 10 cm/sec
Lift speed (lower) w / w.o. load 27 / 15 cm/sec
Description
Lift height
HC 110
1600
HC 110
2500
HC 110
3000
h
1
Height 2100 1850 2100 mm
h
3
Lift 1600 2500 3000 mm
h
4
Mast height extended 2100 3055 3550 mm
h
13
Lowered height 90 90 90 mm
y Wheel base 1335 1335 1335 mm
s/e/l Fork tine dimensions 21/170/1070 21/170/1070 21/170/1070 mm
l
1
Overall length 1755 1755 1755 mm
l
2
Headlength 685 685 685 mm
b
1
Truck width 722 722 722 mm
b
5
Outer load fork distance 580 580 580 mm
b
11
Track width, rear 410 410 410 mm
Ast Working Aisle Width
800x1200 traverse
2175 2175 2175 mm
Ast Working Aisle Width
800x1200 longit.
2145 2145 2145 mm
Lift motor, output where
s
3
10%
1,6 1,6 1,6 kW
Battery voltage, rated
capacity k
5
12/70 12/100 12/100 V / Ah
Battery weight 24 38 38 kg
