4.4 Interface Overview
WMT 210
Switch for autostart (OFF:ON) – standard: off
Power supply (PE – 0 VDC – Ignition - +12 to +48 VDC)
Grounding (PE) – 1,5mm² flat plug contact
COM1 (RS232) with optional 5V power supply on pin 9
2 x Ethernet 10/100/1000 Mbit RJ45
Connection socket (RP-SMA male) for external WLAN antenna (activated via configuration center)
Connection for UPS (uninterruptible power supply)
Use grommets to ensure IP65 protection. The grommets have a slot on the side for inserting the cables.
For strain relief, an additional cable tie can be attached over the corresponding opening on the outside.
